| Double pilot operated check valve | ||||||||
| Symbol | Order Code | Pilot Ratio | Pressure (bar) | Flow (L/min) | Port | Structure | Page | |
|
|
02P035205 |
7.1:1 | 350 | 40 | G3/8 | Flange | 50 | |
02A025301 |
5:1 | 350 | 20 | G1/4 | In line | 51 | ||
02A025302 |
7:1 | 350 | 20 | G1/4 | In line | 51 | ||
02A025303 |
10:1 | 350 | 20 | G1/4 | In line | 51 | ||
02A035101 |
4.7:1 | 400 | 40 | G3/8 | In line | 52 | ||
02A035102 |
4.7:1 | 400 | 40 | G3/8 | In line | 52 | ||
02A035315 |
4.6:1 | 350 | 30 | G3/8 | In line | 53 | ||
02P035201 |
7.1:1 | 350 | 40 | G3/8 | Flange | 54 | ||
02A035108 |
7.1:1 | 400 | 40 | G3/8 | In line | 55 | ||
02P045204 |
6.3:1 | 350 | 60 | G1/2 | Flange | 56 | ||
02A035316 |
4.6:1 | 350 | 35 | G3/8 | In line | 57 | ||
| Flow | 20, 30, 35, 40, 60 |
|---|---|
| Port | G1/4, G3/8, G1/2 |
